LIFTING CAPACITY:
up to 4,10 tm
up to 4,10 tm
MAX OUTREACH:
up to 5,85 m
up to 5,85 m
OVERALL DIMENSIONS:
l 0,92 m , w 0,42 m , h 1,64 m
l 0,92 m , w 0,42 m , h 1,64 m
HYDRAULIC EQUIPMENT:
Walvoil monobloc distributor bank
immediate stop device and pressure gauge
Walvoil monobloc distributor bank
immediate stop device and pressure gauge
CHARACTERISTICS:
with linkage (.1)
rotation with hydraulic motor and pinion mechanically limited to 337°
with linkage (.1)
rotation with hydraulic motor and pinion mechanically limited to 337°
STANDARD
![MOL - Manual Outriggers Lock](/images/stories/technochips/icone85x85/control/mol.gif)
MOL - Manual Outriggers LockA security system that detects the engagement of the safety latch of the primarily locking pin of side manually extendable outrigger supports, at rest in the transport position. It is completed by a visualizer with visual and acoustic alarm, to install on the dashboard of the vehicle cab.
![CPM - Crane Position Monitoring](/images/stories/technochips/icone85x85/control/cpm.gif)
CPM - Crane Position MonitoringA security system that detects if the lateral extension supports of the outriggers are fully retracted, both for manually and hydraulically extendable outrigger supports. Linked to the height check system of the crane, at rest in the transport position, it is completed by a visualizer with visual and acoustic alarm, to install on the dashboard of the vehicle cab.
![MPES - Multi Power Extension System](/images/stories/technochips/icone85x85/performance/mpes.gif)
MPES - Multi Power Extension SystemA Fassi system that guarantees an exceptional extension/retraction speed of the telescopic booms, built up by a set of equally powerful independent rams, linked in series connection and activated by a single control. Special independent fixing system of the extension rams to guarantee high vertical lifting performances.
![UHSS - Ultra High Stregth Steel](/images/stories/technochips/icone85x85/strength/uhss.gif)
UHSS - Ultra High Stregth SteelUltra high strength steel used for the construction of the Fassi structural components, with a high elastic limit, increases structural strength and resistance of the components and at the same time reduces the weight of the crane, to the benefit of the loading capacity of the vehicle which increases.
![FWD - Fewer Welds Design](/images/stories/technochips/icone85x85/strength/fwd.gif)
FWD - Fewer Welds DesignFewer welded joints, the stronger the structure will be. Structural components made out of bended steel with a welded closing plate in lieu of four corners welded structures or monolithic structure likes those for the outer boom and sliding sections with one single welded side: balanced elasticity under load and ideal resistance to fatigue.
![CQ - Cast Quality](/images/stories/technochips/icone85x85/strength/cq.gif)
CQ - Cast QualityFassi use for more then 35 years cast components with high mechanical characteristics for various important structural components, such as the bottom section (pinion) and the head of the column, the column support, the heads of the ram rods and the cylinder bottoms, the connecting rods and other minor components: less weldings, higher performance to fatigue cycles.
OPTIONAL
